Product Details:
|
| Name: | Precision Welded Steel Pipe | Thickness: | 0.3-3mm |
|---|---|---|---|
| OD: | 12-40mm | Length: | 3-6m |
| Keyword: | Steel Pipe | Technique: | Cold Drawn |
| Material: | 1010,1020,1035,1045,Alloy Steel | Surface Treatment: | Annealing |
| Standard: | STKM11A | Section Shape: | Round |
| Alloy Or Not: | Not Alloy | ||
| High Light: | Welded Steel SPCC Pipes,Welded SPCC Pipe 12mm,Welded SPCC Pipes 12mm |
||
Outer Diameter:0.3-3mm
Thickness:12-40mm
STKM11A is the steel grade of carbon steel pipe for Mechanical Structure.
| STKM 11A Chemical Components and Mechanical Performance | ||||||||||||
Standard |
Grade |
Chemical Components | Mechanical Performance | |||||||||
| C | Si | Mn | P | Cu | Ni | S | Cr | Tensile Strength (Mpa) |
Yield Strength (Mpa) |
Elongation (%) |
||
| STKM11A | A | 0.07-0.14 | 0.17-0.34 | 0.35-0.65 | ≤0.35 | ≤0.25 | ≤0.25 | ≤0.04 | ≤0.15 | ≥335 | ≥205 | ≥31 |
Foreign Brand
| GB | ASTM | JIS | EN |
| 08F | 1008 | SPHD/SPHE | DC01 |
Product Features
1. The outer diameter is smaller.
2. High precision and small batch production
3. The cold drawn (rolled) finished product has high precision and good surface quality.
4. The cross-sectional area of the steel pipe is more complicated.
5. The performance of the steel pipe is more superior, and the metal is relatively dense.
Application
1. Automotive and mechanical pipes
2. Petroleum cracking pipes
3. High Pressure Boiler Pipe
4. Low and middle pressure fluid transportation pipeline
5. Chemical fertilizer equipment pipe
