Product Details:
|
| Product: | Q345B 16Mn Hot Rolled Seamless Steel Pipe | Thickness: | 2-70mm |
|---|---|---|---|
| OD: | 15-820mm | Surface: | Black |
| Technology: | Hot Rolled | Alloy Or Not: | Alloy |
| Packing: | Standard Sea-worthy Packaging | Type: | Low Alloy Steel Pipe |
| Standard: | ASTM,GB,JIS,DIN,API | Application: | Ship Pipe,Boiler Pipe |
| High Light: | 16Mn Hot Rolled Seamless Steel Pipe,Hot Rolled Seamless Steel Pipe DIN1629,ST52 alloy steel seamless pipe |
||
OD Size Range: 15-820mm
Thickness Size Range: 2-70mm
Material: DIN1629 ST52 Q345B 16Mn
16Mn is a Low-alloy high-strength structural steel: the carbon content is 0.1%-0.25%, and the main alloying elements manganese, silicon, vanadium, niobium and titanium are added.
Chemical Composition
| C | Si | Mn | P | S | Cr | Ni | Cu |
| 0.13~0.19 | 0.20～0.6 | 1.2~1.6 | ≤0.03 | ≤0.02 | ≤0.15 | ≤0.3 | ≤0.25 |
Mechanical behavior
Tensile strength: 470~660N/mm2
Yield strength: 275~345N/mm2
Elongation: 21%.
Main Features
Good comprehensive performance, good low temperature performance, good stamping performance, good welding performance and machinability.
Applications
Ships, boilers, pressure vessels, oil storage tanks, bridges, power station equipment, hoisting and transporting machinery and other welded structural parts with higher loads.
Delivery Status
The steel is delivered in hot rolled, controlled rolled, normalized, normalized + tempered, thermomechanical rolled (TMCP) condition.
