Product Details:
|
| Name: | Cold Rolled Precision Seamless Steel Pipe | Material: | 16Mn ST52 Q345B |
|---|---|---|---|
| Thickness: | 2-8mm | OD: | 12-76mm |
| Surface: | Bright | Payment: | T/T,LC |
| Length: | 3-m | Tolerance: | ±1%,±5%,±10% |
| Keyword: | Precision Steel Pipe | Technology: | Cold Rolled |
| High Light: | Q345B precision steel pipe,precision steel pipe Bright Surface,Cold Rolled astm pipe |
||
Outer Diameter: 12-76mm
Wall Thickness: 2-8mm
Main Material: 16Mn Q345B ST52
16Mn Precision Seamless Steel Pipe is a kind of high-precision steel pipe processed by cold drawing or hot rolling. Due to the advantages of precision seamless steel pipe without oxide layer on the inner and outer walls, high pressure without leakage, high precision, high finish, no deformation in cold bending, flaring, flattening without cracks, etc.It is mainly used to produce pneumatic or hydraulic components. Products, such as cylinders or oil cylinders, are made of seamless pipe.
| Product Name | 16Mn Precision Seamless Steel Pipe |
| Thickness | 2-8mm |
| Diameter | 12-76mm |
| Standard | GB, ASTM, DIN, JIS |
| Material | 16Mn5 Q345B ST52 |
| Surface | Oiled and Bright |
| Packing | Standard Export Packing, Or According to Customer Requirements. |
| Application |
Precision Machinery,Automobiles,Motorcycles,Electric Vehicles Petrochemicals |
| Port of delivery | QINGDAO, TIANJIN and SHANGHAI |
| Payment term | T/T or L/C |
| Certificate | ISO 9001 |
| Lead time | 15-50days according to order quantity |
| MOQ | 5tons each size |
| Type | seamless |
| Technique | Cold Rolled |
| Inspection | Acceptable |
| Price term | FOB,CIF,CFR |
Application
Cold Rolled Precision Steel Pipe are widely used in Automobiles, Motorcycles, Electric Vehicles, Petrochemicals, electric power, ships, Aerospace, Bearings, Pneumatic Components, Medium and Low Pressure Boiler pipe, Steel Sleeves, Bearings, Hydraulics, Machining and other fields.
Process
Tube blank - inspection - peeling - inspection - heating - perforation - pickling and passivation - grinding - lubrication and air drying - cold rolling - degreasing - cutting head - inspection - marking - Product packaging.
Delivery Conditions
BKS(+SR): After the final cold drawing process there is a stress relieve heat treatment in a controlled atmosphere.
When the 16Mn precision seamless steel pipe is heated, the workpiece is exposed to the air, and oxidation and decarburization often occur (that is, the carbon content on the surface of the steel part is reduced), which has a very adverse effect on the surface properties of the parts after heat treatment. Therefore, the metal should usually be heated in a controlled atmosphere or protective atmosphere, in molten salt and in vacuum, and can also be protected by coating or packaging methods.
Packing & Delivery
Main standards: DIN2391, DIN2445, EN10305, DIN1629, DIN1630, ASTM A179.
