Product Details:
|
| Product: | Hot Rolled Seamless Steel Pipe | Thickness: | 2-50mm |
|---|---|---|---|
| OD: | 12-711mm | Surface: | Black |
| Technology: | Hot Rolled | Usage: | Building Structure |
| Alloy Or Not: | Non-Alloy | Packing: | Standard Sea-worthy Packaging |
| Type: | Seamless | Grade Group: | ST35-ST52 |
| Highlight: | 50mm seamless black steel pipe,2mm seamless black steel pipe,Hot Rolled smls steel pipe |
||
OD Size Range: 12-711mm
Thickness Size Range: 2-50mm
Material: Q195,Q235,Q345, 27SiMn, 12Cr1Mov, 15CrMo
Seamless steel pipe is a steel pipe perforated from a whole round steel, and there is no weld on the surface, which is called seamless steel pipe.
A steel pipe without seams along the perimeter of its cross-section. According to different production methods, it is divided into Hot Rolled Pipe, Cold Rolled Pipe, Cold Drawn Pipe, extruded pipe, pipe jacking, etc., all of which have their own process regulations.
From the Process
The seamless tube is formed by rolling, heated with round steel, pierced, hot rolled, sizing and straightened.
The materials are ordinary and High Quality Carbon Structural Steel (Q215-A~Q275-A and 10~50 steel), Low Alloy Steel (09MnV, 16Mn, etc.), alloy steel, stainless acid-resistant steel, etc.
According to the use, it is divided into two categories: General Use (for water, gas pipelines and structural parts, mechanical parts) and Special (for boilers, geological exploration, bearings, acid resistance, etc.)
|
Standard |
ASTM |
EN |
JIS |
GB |
|
ASTM A106 ASTM A178 ASTM A210 ASTM A369 ASTM A53 ASTM A135 ASTM A524 ASTM A333 ASTM A334 ASTM A 250 ASTM A209 ETC |
EN 10216-2-2002 EN 10217-2-2005 EN 10216-1-2002 EN 10217-1-2002 ETC |
JIS G3454-2005 JIS G3455-2005 JIS G3461-2005 JIS G3467-1988 JIS G3456-2004 JIS G3460-1988 JIS G3464-1988 JIS G3458-2005 JIS G3462-2004 ETC |
GB 9948-2006 GB 6479-2000 GB3087-1999 GB 5310-1995 ETC |
|
|
Material |
Carbon steel grade: ASTMA179,A192,A178 GR.C,A210 A1,ASTM A210 C,DIN 17175 ST35.8, ASTM A53(A,B),ASTM A106(A,B,C); 10#,20G,20mnG,25MnG,,19Mn5,ST45.8-III Alloy steel grade: ASTM A213 (T2,T11,T12,T22,T9),ASTM A200 T5,ASTM A199 (T11,T22), ASTM A335( P2,P12,P11,P22,P5,P9,P23,P91), 16Mn,Q345A,Q345B,Q345C,Q345D,Q345E,15CrMoG, 12CrMo,15CrMo, 13CrMo44,10CrMo910,12CrMo195,X12CrMo91,12Cr2Mo,1Cr5Mo,15Mo3,1 2Cr1MoVG, 12Cr2MoWVTiB,10Cr9Mo1VNb |
|||
Application
1. For buildings, there are many pipelines at the bottom, groundwater extraction when building buildings, boiler hot water transportation, etc.
2. Machining, bearing sleeves, processing machinery parts, etc.
3. Electrical: gas transmission, water power generation fluid pipeline.
4. Anti-static pipes for wind power plants, etc.
Production Process
The main production process of hot-rolled seamless steel pipe (main inspection process):
Tube blank preparation and inspection△→tube blank heating→piercing→tube rolling→steel reheating→fixed (reduced) diameter→heat treatment△→finished pipe straightening→finishing→inspection△ (non-destructive, physical and chemical, Taiwan inspection)→warehousing
Our Company
Shandong Huiyuan Metal Material Co., Ltd. is located in Liaocheng Economic and Technological Development Zone, Shandong Province,which is known as "Water City North of the Yangtze".
Hui Yuan is a trading company established based on Liaocheng Development Zone Jinyun Steel Pipe Co., Ltd. The factory has more than ten years of professional production experience .Now we have cold rolled seamless steel pipe 12 production lines and hot rolled seamless steel pipe 1 production line,one more hot rolled seamless steel pipe production line is under construction.
Our main products are listed as follows: Hot Rolled steel pipe, Precision Cold Rolled steel pipe, Cold Drawn steel pipe, alloy steel pipe, bearing steel pipe, spiral pipe, galvanized pipe,Honed tube,special shape steel pipe.etc.
Our products have been exported to Germany, South Korea, Russia, Malaysia, Pakistan, Thailand, India, Ukraine and other countriesand regions. We sincerely welcome friends from all over the world to contact us and establish mutually beneficial business relations.
